Technical parameters
Basic composition configuration
1.Intelligent cutting software.
It can choose the cutting of special pieces priority, optimize the layout chart and easily control the cutting precision.
2.Perforating device
Use with servo motor , perforating precision, the size of perforating can be changed according to actual requirements.
3.Intelligent servo electrical system
All electrical components are use international first-class brand,
4.Intelligent vacuum pressure system,improve equipment stability and life.
Vacuum pressure can be flexibly adjusted according to requirements，able to self-compensate for pressure during cutting;low noise and strong stability during operation.
5.Integrated bed structure
Effectively maintain the stability of cut fabric and without deformation;conducive to high-load cutting work,ensure high precision level of cutting operation.
6.With air through the convey technology
Equipped with intelligent negative pressure constant system, when convey,so that the fabric in the cutting conveyor will not shift because of the change of pressure.always maintain a stable vacuum state to ensure cutting accuracy and convey efficiency.
| Model | YL-V6 | YL-V8E | YL-V9S |
| Working size (L*W) | 1600*2500mm/2000*2500mm | 2000*2000mm/2000*2500mm/2200*2500mm | 2000*2000mm/2000*2500mm |
| Length of material Pick-up conveyor belt | 2000/2500mm | ||
| Maximum cutting height( After vacuum compression) | 60mm | 80mm | 90mm |
| Maximum cutting speed | 100m/min | ||
| Maximum acceleration | 1.5g | ||
| Maximum rotate speed | 6000r | 4500r | 6000r |
| Maximum cutter acceleration | 2.5m/second | ||
| Machine height | 2169mm | ||
| Knife Intelligent | Option | Option | |
| Main power supply | 5P 380V/50Hz/25Kw/100A(include with 18Kw vacuum device) 5P 380V/50Hz/25Kw/100A(include with 22Kw vacuum device) | ||
| Control power supply | 3P 200V-240V / 50Hz / 16A |
||
| Cutting machine vacuum | 3P 380V/440V,50Hz/60Hz , 30A | ||
| Air pressure | 6.8 Bar | ||
| Air flow volume | 85L/min | ||
| Maximum temperature | 43℃ | ||
| Maximum Humidity | 80(non-condensing） | ||
Basic composition configuration
1.Intelligent cutting software.
It can choose the cutting of special pieces priority, optimize the layout chart and easily control the cutting precision.
2.Perforating device
Use with servo motor , perforating precision, the size of perforating can be changed according to actual requirements.
3.Intelligent servo electrical system
All electrical components are use international first-class brand,
4.Intelligent vacuum pressure system,improve equipment stability and life.
Vacuum pressure can be flexibly adjusted according to requirements，able to self-compensate for pressure during cutting;low noise and strong stability during operation.
5.Integrated bed structure
Effectively maintain the stability of cut fabric and without deformation;conducive to high-load cutting work,ensure high precision level of cutting operation.
6.With air through the convey technology
Equipped with intelligent negative pressure constant system, when convey,so that the fabric in the cutting conveyor will not shift because of the change of pressure.always maintain a stable vacuum state to ensure cutting accuracy and convey efficiency.
We have over 30 years of rich production experience in the manufacturing process of pre-sewing and post-sewing equipment.
